A35电容式传感器(Capacitive sensor)

发布时间:2021-09-06人气:929

JP50电容式传感器(Capacitive sensor)

  • 实现了安装和使用的便捷性;

  • 金属外观和特氟龙外观可选;

  • 检测非金属,包括液体以及颗粒物;

  • The convenience of installation and use is realized;

  • The convenience of installation and use is realized; Metal appearance and Teflon appearance are optional;

  • Detection of nonmetal, including liquid and particulate matter;

输出方式(Output mode)直流三线(DC three wire)
类型(Type)非齐平(Non-Flushed)
检测距离(Detection distance)15mm
漏电流(Leakage current)<0.01mA
设定距离(Set distance)0...12mm
标准目标物(Standard target)--
工作频率(Working frequency)50Hz
消耗电流(Current consumption)≤10mA
负载电流(Load current)200mA
电压降(Voltage drop)≤1.8V
回差(Hysteresis error)4...20%
重复精度(Repeatability)≤5%
LED 显示(Display)LED 红色(red)
保护(Protect)

短路、反极性、过载保护(Short circuit, reverse polarity, overload protection)

工作温度(Working temperature)-20...70℃
温度漂移(Temperature drift)<±10%
防护等级(Degree of protection)IP67
外壳材料(Shell material)PBT/ABS
检测面材料(Inspection surface material)PBT/ABS
缆线长度(Cable length)2m
